If there's one drill you should in your toolbox it's a step drill, they are just the best!
- Multiple sizes in one drill
- Deburs and countersinks
- Works on majority of materials
- Doesn't need a pilot hole
- Drills sheet metal without pulling in
- Brilliant at enlarging holes
- They're fast, and they work!
WHY CHOOSE SPIRAL FLUTE?
Runs cooler at cutting edge, longer life, improved swarf flow, no chatter, increased tool efficiency. It's just better.
FEATURES
Twin flute spiral
Self-starting tip
Laser-etched step sizes
Use in a drill press or battery drill etc
Hex shank for use with an impact driver
SPECIFICATIONS
Step sizes 4, 6, 8, 10, 12, 14, 16, 18, 20, 22mm diameter
Depth per step 4mm
Hex shank 1/4" inch (6.35mm)
M35 HSS with Cobalt coating*
Shank length 25mm
Total length 80mm
FOR MATERIALS
Mild steel
Stainless steel**
Aluminium
Fiberglass
Brass
Copper
Wood
Plastic
NOTES
* The bronze-like colour of the Cobalt coating reduces friction and heat build-up ensuring outstanding durability and sharpness of the cutting edge. Workability is also improved because swarf and chips are less likely to adhere to the cutting surface. Cobalt-coated cutting tools outlast those which are not coated.
** When drilling stainless steel use low speed, high pressure, and cutting fluid otherwise you will get work overheating and work hardening which will damage the step drill.
- Also known as a universal drill, cone drill, or Uni-bit.
- Use cutting fluid to increase tool life.
