The Promax RG5410A-A recovery unit is corrosion-proof and resistant to rough handling. It is designed for use with high-pressure refrigerants and is ideal for residential and appliance service.
FEATURES
> New Generation Compressor, new valves, and piston
> VAC sensor select, selectable low-pressure on/off switch
> Recovers all commonly used CFC, HFC, and HCFC refrigerants including A2L like R32 or R1234yF
> Proprietary oil-less compressor capable of handling both liquid and vapour refrigerants
> 3/8" – 3-row Condensor for maximum performance in even the hardest conditions
> Manual reset high-pressure switch
> Self-purge feature
> Corrosion-proof injection moulded plastic housing
> Field serviceable semi-hermetic compressor
> CE, UL, ARI, and TÜV Approvals
SPECIFICATIONS
Push/Pull Recovery Rate
Lbs/min 10.23, 12.28, 13.71
kg/min 4.64kg, 5.57kg, 6.22kg
Liquid Recovery Rate
Lbs/min 3.46, 3.99, 4.07
kg/min 1.57kg, 1.81kg, 1.85kg
Vapour Recovery Rate
Lbs/min 0.240, 0.33, 0.35
kg/min 0.11kg, 0.15kg, 0.16kg
High Temp Vapour Recovery Rate
Lbs/min 0.15
kg/min
Final Recovery Vacuum 33.6kPa
Refrigerant Loss Weight % 0.02
Residual Trapped Refrigerant <0.05 kg
Motor speed 1725 rpm
Power supply 230V/60Hz
Current draw 10A max
Cable length 1.8m
Weight 14.5kg
Dimensions 19L x 13H x 9W inches
Drive Train: Direct Drive, 1/2HP cap start, inductive run, brushless AC motor
Compressor: > 100:1 compression ratio, air-cooled, machined aluminium alloy components, poppet style valves, hardened oxide coated cylinder walls, with triple Teflon-ceramic polymer piston seals
WHAT YOU GET
1 x RG5410A-A Recovery unit
1 x Filter-drier
Warranty 12 months
