FEATURES
> Free wheel and non-free wheel capability
> Brake lockout function
> Encapsulated bearings
> Zero percent light loading
> New patented braking system
> New design double pawl safety springs to eliminate sticking
> New style cast hand wheel for added strength and durability
> "T" type hooks to improve load-holding integrity with additional chain wear guides and guards (except for the 250kg capacity)
> No aluminium content which suits mining applications
> UV powder-coated paint to protect against sun exposure
> Compliant with European Standards EN13157 and AS1418.2
SPECIFICATIONS
Capacity 3.2T
Lifting height 1.5 m
Test load 4800 kg
Effort to lift full load 360 N
No of fall 1
Load chain 10mm x 28mm
Lever handle length 418mm
Weight 16.5 kg
OPTIONAL
> Overload Protection
NOTE
> Please contact us if you require a greater lift height, this can be modified to meet your criteria.
