THIS ITEM IS AVAILABLE ON SPECIAL ORDER. PLEASE CONTACT US TO CONFIRM PRICE AND AVAILABILITY.
The JDN Mini Air Hoist Food Grade model is specifically made for use in the food and beverage industries. It meets the hygienic requirements and perfectly complements the HACCP plan.
FEATURES
> Easy to clean
> Motor housing made of uncoated cast aluminum chain
> Stainless steel chain, chain inlet, load sleeve and hooks
> Corrosion and humidity resistant
> Mechanical and pneumatically driven
> Resistance to water and other cleaning agents
> Food grade lubricant with the H1 certification
> All screws, nuts, and other elements have been replaced with corrosion resistant parts
> Safe for use in areas where flammable chemical substances are handled
> Lubricated by fully synthetic grease suitable for food and pharmaceutical industry
> NFC tag allows access to certificates, instructions and maintenance information of each unit via JDN service app
SPECIFICATIONS
Capacity 125 kg
Air pressure 6 bar
Lifting speed at full load 20m/min
Lifting speed without load 40m/min
Lowering speed at full load 40m/min
Lowering speed without load 25m/min
Air consumption at full load – lifting 0.95 m3/min
Air consumption at full load – lowering 0.95 m3/min
Lifting height 5m
Control length 4m
Chain dimension 4.7 x 14.1mm
Chain fall 1
Weight at 5m lift/4 m control length 11kg
Hose inside dia 13mm
Air connection G 1/2
ATEX zone 2/22
OPTIONAL
> Stainless steel trolley
> Stainless steel chain bag
> Conversion kit offers twist lock hook
> Stainless steel air inlet
12 MONTHS WARRANTY
NOTES
What's the difference between and WINCH and a HOIST?
WINCHES are for PULLING - A 1000Kg winch could probably only lift 100Kg
HOISTS are for LIFTING - A 200Kg hoist could probably pull a 1000Kg load
Pulling is easier than lifting and a lifted load needs to be stopped with a brake.
