Description
IMPORTANT SHIPPING CRITERIA FOR THIS ITEM
This item is over 25Kg so it must be sent by Transport (i.e. collected and delivered by truck). The standard delivery charge calculated at checkout only covers delivery to town and city CBD business addresses (and if applicable the local freight depot). Unfortunately, it does not cover working from home business addresses. If you are unsure if your address qualifies for the standard shipping rate or want to have this item delivered to a home or rural address please contact us for a quote before ordering.
FEATURES
Thermal overload Protection
Light weight compact design combined with high efficiency.
Pressed steel structure
High tensile alloy steel top bottom hooks
Grade 80 - 7.1mm Alloy Steel load chain.
Limit switches top and bottom to prevent chain runout.
SPECIFICATIONS
Capacity 1 Ton
Single phase 230V 1200W
Lifting height 3m
Single Speed 6m/min
Chain link dia. 7.1mm
Hook to hook 480mm minimum
Pendant cable 2.5m (extendable)
Duty cycle 30% over 10 minutes
Relative humidity <85%
Ambient temperature -25ºC - 40ºC
Working class: M4
Level of Protection: IP54
Weight 60Kg
Minimum head room 520mm
Extension chain available separately by the metre, contact us for a quote.
