IMPORTANT SHIPPING CRITERIA FOR THIS ITEM
This item is over 25Kg so it must be sent by Transport (i.e. collected and delivered by truck). The standard delivery charge calculated at checkout only covers delivery to town and city CBD business addresses (and if applicable the local freight depot). Unfortunately, it does not cover working from home business addresses. If you are unsure if your address qualifies for the standard shipping rate or want to have this item delivered to a home or rural address please contact us for a quote before ordering.
FEATURES
Thermal overload Protection
Light weight compact design combined with high efficiency.
Pressed steel structure
High tensile alloy steel top bottom hooks
Grade 80 - 7.1mm Alloy Steel load chain.
Limit switches top and bottom to prevent chain runout.
Complies with ASNZS1418.2 standard
SPECIFICATIONS
Capacity 1 Ton
3 phase 415V 1200W
Lifting height 6m
2 Speed 1.2 and 3.5 m/min
No of chain 1
Chain link dia. 7.1mm
Running test load: 12.5 kN
Extra Weight per metre of extra lift: 2.2 kg
Weight 68Kg
Extension chain available separately by the metre, contact us for a quote.
