FEATURES
- Can be combined with a 4-point or 6-point pushbutton and used as a motorized trolley or overhead traveling crane.
- The electric chain hoist with a chain-driven trolley is suitable for relatively heavy loads not transported a long distance.
- The electric chain hoist with a manual-driven trolley is suitable for relatively light loads transported a short distance.
- Trolleys are fitted with Guide Rollers as standard to reduce wear and ensure suitability for curved beam applications.
SPECIFICATIONS
- Rated Capacity 2 ton
- Girder width 100-150mm
- ETN Speed m/min 21.5 / 5.3 dual speed
- Motor 0.14kw 3 phase
- Weight 52kg
- Min Radius 1.8m
Larger girder widths are available on request, please contact us to enquire.
Please contact us if you require a longer pendant cable, this can be modified to meet your criteria.
