JDN PROFI Air Hoist 0.5T Cord Control JDN706

JDN706
Contact us for a price
In stock
Shipping Information
Find similar
Description

THIS ITEM IS AVAILABLE ON SPECIAL ORDER. PLEASE CONTACT US TO CONFIRM PRICE AND AVAILABILITY



The JDN Air Hoists PROFI Series are designed and manufactured to be extremely robust, no downtime, and explosion safe. They are not susceptible to external influences and are extremely low maintenance.


FEATURES
> Custom-made for tough and demanding industrial applications and continuous operation
> Dust-protected ball bearings
> Permanently lubricated planetary gear with high-performance lubricant
> Gears made of hardened or tempered stainless steel
> Comply with AS1418.2
> 100% duty rating and unlimited duty cycle
> Resistant to dirt, dust, moisture, paint particles, spray mist, and aggressive vapours
> Mechanical and pneumatically operated
> Engines are specially lubricated with high-performance lubricant
> Ensured by the non-slip, low-maintenance multiblade motor
> ATEX–approved models available perfect for application in dangerous and explosive environments
> ATEX EX II 3GD IIA T4 Regulations - GAS ZONE 1&2/DUST ZONE 21&22
> Patented pre-lube motor design for low maintenance, oil-free operation
> Made in Germany

SPECIFICATIONS
> Capacity 0.5T (500 kg)
> Air pressure 6 bar
> Number of chain strands 1
> Engine power at full load 1kW
> Lifting speed at full load 11m/min
> Lifting speed without load 19m/min
> Lowering speed at full load 17m/min
> Air consumption at full load – lifting 1.2 m3/min
> Air consumption at full load – lowering 1.5 m3/min
> Lifting height 3m
> Cord length 2m
> Air connection G 1/2
> Operating temperatures -20C  to +70C

OPTIONAL
> Chain container
> Increased ATEX Protection (Zone 1, Group IIB, Gas Zones 1 & 2 Group IIC. Increased paint protection, spark-proof)

WHAT YOU GET
> 500kg JDN Profi Air Hoist Cord control
> 3m Chain length


12 MONTHS WARRANTY


NOTE
> Please contact us if you require a greater lift height or specific application requirements.



What's the difference between and WINCH and a HOIST?

WINCHES are for PULLING - A 1000Kg winch could probably only lift 100Kg
HOISTS are for LIFTING - A 200Kg hoist could probably pull a 1000Kg load

Pulling is easier than lifting and a lifted load needs to be stopped with a brake.
