Juuko K202R Remote Control Variable Speed 2 Button CDK202R

THIS JUUKO REMOTE CONTROL VARIABLE SPEED MAY BE ADDED TO ANY PACIFIC PORTA HOIST - CONTACT US TO DISCUSS YOUR NEEDS

FEATURES

• Automatic Channel Switching
• Multi-control system - master/slave, pitch and catch, tandem
• Control dial can adjust the output from 0 to 10 volts and adjusts the slow speed on the Porta Hoist from a variable 0-4.8m/min
• Activation of the transmitter is protected by an electronic key-code and an auto shut-off option which is programmable
• The system automatically changes to another frequency in the presence of radio interference
• Eco power management system. Save on batteries
• It can receive and display via 4 LEDs signals coming from the receiver
• Mushrooms type EMO button
• Internal BootLoader, update firmware by using computer
• Wireless pairing procedure using the keyboard pushbuttons
• QI wireless charging pad is optional in the New 2016 K plus series
• The zero-g safety function can prevent the uncontrolled output of commands in specific emergencies
• The G sensor can detect if the transmitter receives a hard impact, dropped, or thrown
• Ultra-high impact resistant corner bumpers reinforced for firmer grip and added protection in case of drop
• Stainless legs on the back give the case lay-on-the-ground protection
• Matte black rubber-tone backside is durable and offers a secure grip
• The receiver is constructed specifically for the Pacific Porta Hoist and is fully enclosed within the hoist housing

TRANSMITTER SPECIFICATIONS

• Button 2
• Size 193 x 57 x 51mm
• Frequency band 433MHz
• Typical operating range 100m
• Radio-frequency power <10dBm
• Control System PLL
• Antenna Type and Impendance 50ohm
• Average power consumption 16mA a 3Vcc
• Operating and storage temperature -25°C)-(+55°C) / (-40°C)-(+85°C)
• Housing material PA(30%fg)
• Protection degree IP65
• Power supply DC3V (LR6(AA)1.5V*2)
• Weight 325g

HS RECEIVER SPECIFICATIONS

• Size 193 x 57 x 51mm (2-8 buttons)
• Pushbutton 2, 4, 6, 8, rotary switch single/double pressure motion button
• Frequency band 315 / 418 / 429 / 433 / 447 / 470 / 915 MHz / 2.4 GHz
• Channel space 12.5 kHz
• Hamming distance ≥ 15
• Stop command response time - 50 ms
• Command response time - 50 ms
• Number of available on/off command max. 24 + Start and EMO
• Operating and storage temperature (-25°C)~(+55°C) / (-40°C)~(+85°C)
• Housing material PA6 (GF30%)
• Radio communication bi-directional
• Protection degree IP65
• Power supply LR6(AA)1.5V / NiMH(AA)1.2V x2
• Weight 350g

The Juuko remote control system is available with all Hitachi Hoists, contact us to choose the correct setup for your job.
There is a 1 week lead time for hoists sold with remote control or custom chain lengths.
