Description
FEATURES
> Operates in any position; horizontal, vertical and angled
> Compact and lightweight design for confined or limited spaces
> Easy to operate and anchor onto a variety of structures
> All steel construction (including rope) and contains no aluminum
> Suitable for many industries including underground mining and 4WD and off-road applications
SPECIFICATIONS
Rated Capacity 3200kg
Forward lever action angle range 111 degrees
Wire rope diameter 16mm
Wire rope safety factor 5 times
Static load safety factor 4 times
Max dynamic load 4000kg
Net weight without rope 22
Wire rope standard length 20m
