FEATURES
- Self-levelling
- Variable-speed
- Scan-angle selection
- Manual dual slope setting
- High level of accuracy
- IP56 rating against dust and water
- Rotational laser for horizontal and vertical application
SPECIFICATIONS
Laser diode: Line 630 - 650 nm, < 5mW
Operating temperature: -10 to 50 °C
Storage temperature: -20 to 70 °C
Laser class: 3R
Working range value: 60m dia
Working range: up to 60m dia
Working range with receiver 350m dia
Accuracy: ±1.5 mm at 30m horizontal, ±3 mm at 30m vertical
Self-levelling range: ±5° (8%)
Dust and splash protection: IP56
Rotation speed 0/150/300/600 min?1
Power supply: 2 x 1.5V LR20 (D)
Operating time (max.): 30h
Tripod thread: 5/8"
Colour of laser line: red
Color of plumb points: red
Weight: 1.8 kg
WHAT YOU GET
1 x Laser receiver LR30
1 x Receiver bracket RB30
1 x Wall mount WM4
2 x 1.5 V LR20 battery (D)
1 x 9V block battery (6LR61)
1 x Laser viewing glasses (red)
1 x Laser target
User manual
6 Year Warranty including Trade upon registration
Bosch product number 0 601 061 S40
