FEATURES
- Self-levelling
- High level of accuracy
- IP68 rating against dust and water
- Dual slope setting
- 125mm reception area
- Long runtime both with 18V battery system
SPECIFICATIONS
Battery voltage 18V (not included)
Laser diode: Line 630 - 650 nm, < 10mW
Operating temperature: -10 to 50 °C
Storage temperature: -20 to 50 °C
Laser class: 2
Working range with receiver: 600m dia
Working range without receiver: 60m dia
Accuracy: ± 1.5 mm at 30 m* horizontal (*plus use-dependent deviation), ± 3.0 mm at 30 m* vertical (*plus use-dependent deviation)
Self-levelling range: ±8.5% (±5°)
Dust and splash protection: IP68
Rotation speed 150/300/600 min?1
Power supply: 4 x D cell batteries, 18V Li-ion battery (not included)
Operating time (max.): 60h, 70h
Tripod thread: 2 x 5/8"
Projection: 1 x 360° line
Compatible laser receivers: LR60
Weight: 4.6 kg
WHAT YOU GET
1 x Laser receiver LR60
1 x Receiver bracket RB60
1 x Remote control RC6
1 x Quick charger GAL18V-40
1 x Battery adapter BA1
1 x Wall mount WM6
1 x Laser target plate
4 x 1.5 V LR20 battery (D)
4 x 1.5 V LR6 battery (AA)
1 x Laser viewing glasses (red)
Carrying case
6 Year Warranty including Trade upon registration
Bosch product number 0 601 061 F40
