The GCM 12 GDL does away with rails entirely, replacing them with the Axial Glide System, two hinged arms operating at right angles to each other with high quality sealed ball bearings that provide a frictionless glide that allows for cramped workshops or use on building sites where space is at a premium. Bosch claims that the glide system components will never need maintaining.
All controls for the mitre and bevel settings are located on the front of the machine. The GCM 12 GDL has and two extendable material supports that slide out from the base.
FEATURES
- Axial Glide system
- Soft start
- Electric brake
- High power motor for fast cutting
- Front bevel adjustment controls
- Max cutting capacity 91 x 187mm
- Dual guide lasers
SPECIFICATIONS
Blade diameter 305mm (12")
Cutting capacity 0 degrees 104 x 341mm
Cutting capacity 45 degrees mitre 104 x 240mm
Cutting capacity 45 degree incline 51 x 341mm
Mitre setting 52 degrees L / 60 degrees R
Incline setting 47 degrees L / 47 degrees R
Dimensions 673W x 822L x 686H mm
Input power 2000W
No-load speed 3,800rpm
Blade bore 30mm
Weight 32.1kg
WHAT YOU GET
Bosch Axial Glide Mitre Saw 305mm (12") GCM12GDL 0601B23640
Multi-purpose 305mm 60 tooth blade
Vertical clamp
Service tool
Dust bag
Insert plate
User manual
6 Year Warranty including Trade upon registration - With service agents Nationwide
Bosch part number 0 601 B23 640
